011556115
Invoice Description:
M4/6D2.SNBT
Catalog Description:
Gray, heavy duty switch and fuse holder block with 6 mm spacing, 15 Amp rated UL current with screw clamp connection that accepts 24-12 AWG UL wire range
Ready to order this product?
Get Quote on Gross AutomationNeed Help?
Call 1-877-268-3700 or email sales@grossautomation.com
Product Specifications
| Attribute | Value |
|---|---|
| _Features_5 | Compensates for the flattening of copper under con |
| _UL Wire Range (AWG) | 24-12 |
| Sub Brand | Entrelec |
| Color | Gray |
| Connection | Screw Clamp |
| Type | SNA Terminal Blocks |
| Size | 3.19 x .238 x 2.56 |
| Mounting | DIN 1-3 |
| _Features_1 | Self-locking clamp design prevents screw loosening |
| Application | For use with applications ranging from standard di |
| _Features_3 | Touch-safe IP20 protection |
| _Features_2 | Quick fuse installation and replacement |
| Voltage Rating | 300 V |
| Amperage Rating | 15 A |
| Wire Size | 12 |
| _Style | Double Deck Heavy Duty Switch and Fuse Holder |
| _Features_4 | High quality steel offers a very high over-torque |
| Brand Name | ABB |
| Spacing | 0.236 IN |
| _Features_6 | Clamp is protected from harsh environments by a zi |
